AC PSC Motor- 701

Model #: 701
PSC Clamp-On Motor, 230VAC, 50/60Hz, 0.16hp (120W)
AC PSC Motor- 701
Agency logo
Agency logo

$120.00 / Piece

Typical Lead Time: 60 Days

Delivery and Return Information

Demo (110)
  • PSC Motor
  • Clamp-On Mounting type to fit a wide range of PROCON Pumps
  • Manufactured to be robust and reliable for a wide range of industries and applications
  • 230VAC, 50/60Hz, 0.16hp (120W)
    • Technical Information
    Flow Rate GPH 50GPH (150LPH)
    Agency Approvals UL & CE
    Product Weight 6.9lb (3.13Kg)
    Operating Range
    Max Sound Level 60dB(a)
    Motor Performance
    Motor Speed 2 1650RPM
    Speed 1320RPM
    Power (hp) 0.16
    Voltage 230V
    Motor Voltage 2 16
    Motor Current 1A
    AC/DC AC
    Motor Mount Type Clamp-On
    Motor Design IMB3
    Protection IP20
    Motor Insulation F
    Frequency 50/60Hz
    Motor Type PSC
    Cooling Type No Cooling
    Phase Single Phase
    Power (W) 120W
    Motor Capacitor 7?F
    Motor Poles 4
    Capacitor Voltage Rating 440VAC
